Eaton S20N11S07N 240 x 480 Volt Primary 120/240 Volt Secondary 7.5 kVa 1-Phase Encapsulated Transformer

Product Description

Eaton S20N11S07N is a general-purpose encapsulated transformer designed for reliable power distribution. This transformer operates at 240 x 480 volts for the primary side and 120/240 volts for the secondary side. It provides a power rating of 7.5 kVa and is suitable for one-phase applications. The unit is encapsulated in a durable mix of epoxy-coated sand and gravel, ensuring longevity and performance even in demanding conditions.

• Meets ANSI, NEMA, and IEEE standards.
• Indoor and outdoor application compatible.
• Constructed with aluminum windings.

Product Highlights

This Eaton transformer is ideal for commercial and institutional buildings, ensuring efficient energy distribution in various applications. Designed for continuous operation at the rated kVA, it helps maintain optimum energy flow.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: S20N11S07N
• Type: Encapsulated Transformer
• Primary Voltage: 240 V
• Secondary Voltage: 120/240 V
• Power Rating: 7.5 kVA
• Phase: 1
• Frequency: 60 Hz
• Temperature Rating: 115 degrees C
• Enclosure Type: NEMA 3R
• Dimensions: 9.89 inches L x 10.38 inches W x 16 inches H
• Weight: 124 lb
