EATON S20N11S03N TRANSFORMER DISTRIBUTION 240/480VAC 3KVA

Product Description

The EATON S20N11S03N is a transformer distribution unit designed for 240/480 volt alternating current applications. This transformer features a dry encapsulated design, suitable for both indoor and outdoor environments. It provides a power rating of three kilovolt-amperes and operates at a frequency of sixty hertz and one phase.

• Encapsulated core for efficient heat management
• Lug connection type for secure installation
• NEMA 3R enclosure for weather resistance

Product Highlights

This transformer is a reliable choice for power distribution in commercial and institutional buildings. The rugged construction ensures long-term performance under various conditions.

Product Information

Standard Information

• Manufacturer: EATON
• Part Number: S20N11S03N

Technical Specifications

• Type: Type EP Dry Encapsulated
• Power Rating: 3 kVA
• Primary Voltage: 240/480 VAC
• Secondary Voltage: 120/240 VAC
• Mounting Type: Upright
• Insulation Class: 180 deg C
• Temperature Rise: 115 deg C
• Enclosure Type: NEMA 3R
• Weight: 64 lb
• Dimensions: 8 in L x 7.69 in W x 14.25 in H
• Phase: 1
• Housing Material: Steel
• Frequency Rating: 60 Hz
• Approval: UL Listed
