Eaton S10N06P51P ETN S10N06P51P .5KVA BUCK BOOST XFM

Product Description

The Eaton S10N06P51P is a general-purpose encapsulated transformer designed for reliable power distribution. This model features a power rating of 0.5 kVA with options for 120 and 240 volts primary input and 16/32 volts secondary output. This transformer is encapsulated in epoxy, which enhances its durability.

• Rated for 60 Hz operation
• Single-phase design for versatile applications
• Suitable for indoor and outdoor use with NEMA 3R enclosure

Product Highlights

This transformer is ideal for commercial and institutional buildings. It meets ANSI and IEEE standards for safety and performance.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: S10N06P51P

Technical Specifications

• Frame: 57P
• Height: 9.34 inches
• Length: 5.18 inches
• Weight: 15 lb
• Primary Voltage: 120 V, 240 V
• Secondary Voltage: 16 V, 32 V
• Temperature Rating: 115 degrees C
• Connection Type: 3C
• Frequency: 60 Hz
• Enclosure Type: NEMA 3R
