Eaton S10N04P01P C-H S10N04P01P 1PH 1KVA TFMR

Product Description

The Eaton S10N04P01P is a single-phase,1 kVA encapsulated transformer. This unit is designed for reliable performance in commercial and institutional buildings. Its robust construction ensures it meets the latest ANSI, NEMA, and IEEE standards, ensuring safety and reliability in power distribution applications.

• Single-phase design with a power rating of 1 kVA.
• Encapsulated for enhanced durability and protection against environmental factors.
• Meets various voltage requirements: primary voltage of 120V and 240V, secondary voltage of 12/24V.

Product Highlights

The Eaton transformer is suitable for various applications including commercial and institutional buildings. Its encapsulated design allows for continuous operation while adhering to safety standards.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: S10N04P01P

Technical Specifications

• Primary Voltage: 120 V, 240 V
• Secondary Voltage: 12/24 V
• Frequency Rating: 60 Hz
• Phase: 1
• Frame: 67P
• Temperature Rating: 115 Degrees C rise
• Connection: 3B
• Country of Origin: Mexico
