Eaton S-8202-1 Buss Fuseblock 300 VAC/VDC (10) Replacement MPN

Product Description

The Eaton S-8202-1 Buss Fuse Block is designed for applications that require reliable circuit protection. This model functions at 300 VAC/VDC and supports an amperage rating of 16/20 A with a single pole. The device features a quick-connect connection method for easy installation and a bolted-in mounting system for secure placement.

• Breakaway design for improved reliability.
• Constructed with a thermoplastic body for durability.
• Meets UL and CSA standards for safety.

Product Highlights

This Buss Fuse Block is used in various electrical applications where circuit fuses are required to prevent overload and protect sensitive equipment.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171211759

Technical Specifications

• Type: Breakaway
• Voltage Rating: 300 VAC/VDC
• Amperage Rating: 16/20 A
• Connection Type: Quick-Connect
• Dimensions: 2 in L x 0.5 in W x 0.56 in H
• Fuse Length: 1-1/4 in
• Fuse Diameter: 1/4 in
• Material: Thermoplastic
• Mounting Type: Bolted-In
• Number of Poles: 1
• Temperature Rating: 130 deg C
• Series: 8200
• Standards/Approvals: UL File No. E14853 Guide No. IZLT2 | CE Certified | CSA 6225-01 File No. 47235
