Eaton RM60100-1CR BUS 100 AMP CLASS R FUSE HOLDER 600V -1 POLE

Product Description

The Eaton RM60100-1CR is a modular fuse block designed for electrical assemblies. It operates at 600 volts and supports a current of seventy to one hundred amperes. This one-pole fuse holder features a knife blade end connection, which is suitable for various wire sizes, including 1/0 to 3 AWG and smaller gauges.

• UL Class R certification
• Temperature range from -40 to 120 degrees Celsius
• Constructed from durable thermoplastic material

Product Highlights

The RM60100-1CR is built for flexibility and safety in electrical installations.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171239121
• Invoice Description: RM60100-1CR BUS 100 AMP CLASS R FUSE HOLDER 600V -1 POLE

Technical Specifications

• Amperage Rating: 70 to 100 A
• Application: Electrical Assemblies, Panels and EOEMs Applications
• Class: R
• Connection Type: Knife Blade End
• Dimensions: 6 in L x 2 in W x 2.8 in H
• Material: Thermoplastic
• Mounting Type: Hole
• Number of Poles: 1
• Series: RM Series
• Standards/Approvals: CSA Certified, cULus File No.E14853, RoHS Compliant, UL 94-V-0 Flammability Rating
• Suitable For Use With: Knife Blade Cartridge Fuse
• Temperature Rating: -40 to 120 degrees Celsius
• Voltage Rating: 600 V
