Eaton RM25100-3CR Bussmann 100 Amp Class R Fuse Holder 250V -3 Pole

Product Description

The Eaton RM25100-3CR is a Bussmann modular fuse block designed for electrical assemblies, panels, and original equipment manufacturers. It operates at a voltage of 250 volts and has an amperage rating of seventy to one hundred amps. This three-pole fuse holder is suitable for knife blade cartridge fuses. It features a thermoplastic construction and measures six inches long, six inches wide, and two point eight inches high.

• Integral dovetails for assembly of multiple poles
• Up to four mounting holes per pole
• Meets UL creep and clearance requirements

Product Highlights

This modular fuse block provides flexibility in application and installation, making it suitable for various electrical projects. The design supports robust electrical connections and ensures safety in power distribution.

Product Information

Standard Information

• Manufacturer: Eaton
• Series: RM Series

Technical Specifications

• Voltage Rating: 250 V
• Amperage Rating: 70 to 100 A
• Number of Poles: 3
• Dimensions: 6 in L x 6 in W x 2.8 in H
• Connection Type: Knife Blade End
• Temperature Rating: -40 to 120 deg C
• Material: Thermoplastic
• Standards/Approvals: CSA Certified, cULus File No.E14853, RoHS Compliant
