Eaton RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)

Product Description

The Eaton RD16-3-508 is a Bussmann rotary disconnect switch designed for safe and reliable operation. It features non-fused construction and is suitable for isolating motors and circuits. The switch is rated for six hundred volts AC and sixteen amperes, making it ideal for various applications in stationary machinery and factory settings.

• Front or side handle operation
• Compact design for easy installation on DIN rail or panel
• Fingersafe design enhances user safety

Product Highlights

This disconnect switch allows safe control and disconnection of motor applications while providing a robust design that meets industry standards.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: RD16-3-508

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 16 A
• Horsepower Rating: 10 hp
• Number of Poles: 3
• Temperature Rating: -20 to 70 deg C
• Short Circuit Current Rating: 65 kA
• Application: Stationary machinery equipment in factory and robotics applications
• Actuator Type: Front/Side Handle
• Mounting Type: DIN Rail/Panel
• Standards/Approvals: CE Marking, CSA C22.2 No. 14/257020, cULus Listed, IEC 60947-3, RoHS Compliant, UL 508 File No. E155129
