Eaton R5B3100U Rotary Disconnect Switch 100A

Product Description

The Eaton R5B3100U rotary disconnect switch is a three-pole, non-fusible switch with a 100A amperage rating and a 600V voltage rating. Suitable for use as a motor disconnect, this UL 508 listed switch provides load break switching and isolation for low voltage circuits. It is designed for manual operation and features a modular design.

• Suitable as motor disconnect
• Compact footprint
• Integrated terminals for additional safety
• Product can be reverse fed

Product Highlights

The Eaton R5B3100U rotary disconnect switch offers a compact, economical solution for switching and isolation in commercial and industrial applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: R5B3100U
• Country of Origin: China

Technical Specifications

• GTiN: 00786679188002
• Type: Non-Fusible
• Brand: Eaton - Cutler Hammer
• Height: 2.6 Inch
• Length: 2.06 Inch
• Voltage: 600 Volt
• Amperage: 100 Amp
• Product UPC: 78667918800
• 12-Digit UPC: 786679188002
• Applications: Commercial / Institutional Buildings / Structures - Power Distribution and Controls
• Number of Poles: 3 Pole
• Catalog Number: R5B3100U
• Manufacturer: Eaton
• Country of Origin: China
• Made in USA: No
• Amperage Rating: 100 A
• Application: Commercial / Institutional Buildings / Structures - Power Distribution and Controls
• Standard: CSA Certified,EN Listed,IEC Rated,UL 508,CCC Marked
• UPC: 786679188002
• Item Type: Rotary disconnect switch
• Voltage Rating: 600 VAC
• Actuator Type: Handle
• Mounting Type: DIN Rail
• Series: R5
• Short Circuit Current Rating: 65 kA
• Product Name: Eaton rotary disconnect switch
• Product Length/Depth: 3.5 in
• Product Height: 0.2 in
• Product Width: 2.5 in
• Compliances: CCC Marked
• Certifications: EN Listed IEC Rated CSA Certified UL 508
• Catalog Notes: Suitable as motor disconnect
• Product Type: Rotary disconnect switch
• UNSPSC: 39122217
• Alternate Mfr Part Number: R5B3100U
