Eaton R5B3080U Non-Fusible Rotary Disconnect Switch 80 A

Product Description

The Eaton rotary disconnect switch, model R5B3080U, is designed for industrial applications. This non-fusible three-pole rotary switch is rated at eighty amperes and operates at six hundred volts AC. It is ideal for powering drive and control applications in various industrial settings.

• UL 508 listed for reliable safety and performance
• Compact design for easy installation on DIN rails or surfaces
• Three-pole configuration suitable for motor disconnects

Product Highlights

Offering reliable isolation for low voltage circuits, the R5 series allows for efficient power distribution and control. This switch is modular, making it easy to interface with existing systems.

Product Information

Standard Information

• Catalog Number: R5B3080U
• Manufacturer: Eaton

Technical Specifications

• Voltage Rating: 600 V
• Amperage Rating: 80 A
• Number of Poles: 3
• Dimensions: 2.57 inches L x 2.07 inches W x 3.72 inches H
• Application: Suitable for industrial facilities and control power distribution
• Standards: EN Listed, UL 508, CSA Certified
• Country of Origin: China
