Eaton PV-5A10F Solar Fuse Fast Acting 5A 1000V DC

Product Description

The Eaton PV-5A10F Solar Fuse is engineered for superior performance in photovoltaic systems. Providing fast-acting protection at 1000V DC, this fuse prevents damage to solar panels and other equipment in case of overcurrent.

• High interrupt rating of 20kA ensures reliable protection against electrical surges.
• Compact cylindrical design with ceramic body, measuring 1-1/2 inches in length and 13/32 inches in diameter.
• Compliant with multiple standards including CCC, CSA, IEC 60269-6, and UL 2579.

Product Highlights

Eaton's PV-5A10F model is a non-indicating, fast-acting solar fuse specifically made to offer protection and efficiency in solar energy systems.

Product Information

Standard Information

• Brand: Eaton
• Series: PV-F

Technical Specifications

• Amps: 5 A
• Class: gPV/UL PV
• Speed: Fast Acting
• Length: 1-1/2 inches
• Diameter: 13/32 inches
• Interrupt Rating: 20kA at 1000V DC
• Body Material: Ceramic
• DC Voltage Rating: 1000V DC
