Eaton PSG60E12SM PSG 1-Phase switcher DC power supply 60 W (12 VDC, DIN rail)

EATON
Brand: EATON
SKU: PSG60E12SM
Availability: In Stock

Ships same day if ordered by 12 pm
$212.99
$212.99
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Eaton PSG60E12SM is a PSG series single-phase DC power supply that provides 12 VDC at a 60 W power rating. It accepts a universal AC input and is DIN-rail mountable in a metal enclosure with heavy-duty screw terminals. The unit includes varistor transient surge protection, safety class I grounding, and supports brief current surges up to 150% of nominal for high inrush loads.

  • Input voltage: 100 to 240 VAC; frequency 47-63 Hz; single-phase operation
  • Output: 12 VDC, 60 W with nominal amperage ~5 A; peak current up to 7.50 A (150% for inrush)
  • Metal case, DIN rail mounting, heavy-duty screw terminals, varistor surge protection

Product Highlights

60 W, 12 VDC DIN-rail power supply with universal 100–240 VAC input and transient surge protection

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: PSG60E12SM
  • Country of Origin: Thailand
Technical Specifications
Brand
Eaton
Manufacturer Part Number
PSG60E12SM
Series
PSG
Product Type
AC-DC power supply
Input Voltage
100 to 240 VAC
Frequency
47-63 Hz
Phase
Single-phase
Output Voltage
12 VDC
Power Rating
60 W
Output Current
5 A (nominal) — source lists 1.35/5 A; 5 A consistent with 60 W at 12 V
Peak Output Current
7.50 A (150% peak for inrush)
Mounting Type
DIN Rail
Case Material
Metal
Terminal Type
Heavy-duty screw
Protection Features
Varistor transient surge protection; safety class I grounding; overvoltage and short circuit protection
Operating Temperature Range
-20 to 75 C
IP Rating
IP20
Output Noise
Less than 50 mV
Hold-up Time
Greater than 22 ms
Status Indicator
Green DC OK signal
Connection
Screw terminal
Certifications
cULus/UL 60950-1; UL 508; CSA; IEC; CE; RoHS Compliant
