Eaton PJ82W Mid-Size Receptacle Wall Plate

Product Description

The EATON PJ82W mid-size receptacle wall plate features a rugged polycarbonate construction to reduce installation costs by preventing breakage. The exclusive screw-catch feature holds mounting screws captive, simplifying installation. Its high-gloss finish is soil-resistant. Designed for duplex receptacles in two-gang configurations.

• Virtually unbreakable plates reduce installation and replacement costs
• Exclusive time-saving screw catch feature holds mounting screws captive and simplifies installation
• High gloss finish is soil resistant

Product Highlights

This mid-size polycarbonate wall plate offers superior impact resistance and long-term form retention. Matching mounting screws are included.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: PJ82W

Technical Specifications

• Construction: Superior Impact-Resistance
• Cutout: 1.13 in H x 1.34 in W Duplex
• Finish: High Gloss
• Mounting: Screw
• Thickness: 0.08 in
• Type: Mid-Size
• Number of Gangs: 2
• Material: Polycarbonate
• Brand: EATON
• Series: PJ Series
• Height: 4.87 in
• Width: 4.94 in
• Product Length/Depth: 0.08 in
• Compliances: RoHS Compliant
• Certifications: UL Listed, cULus Listed
• Product Type: Duplex receptacle wallplate
• Wallplate size: Mid-size
• Gang: Two-gang
• Manufacturer: EATON
• Application: Commercial, Industrial, Institutional and Other High-Traffic Areas
• Standard & Approvals: UL Listed to UL 514D File No. E33216, cUL, UL File E33216 Certified to C22.2 File No. 42.1, RoHS Compliant
• Includes: Mounting Screws
