Eaton PDG13C0060TFFJ Power Defense PD 60A Molded Case Circuit Breaker

Product Description

The Eaton PDG13C0060TFFJ is a power defense molded case circuit breaker. It is globally rated and designed for various applications. This circuit breaker features a three-pole configuration with a current rating of sixty amps. It has an interrupting capacity of eighteen kiloamperes at four hundred eighty volts. The breaker provides reliable performance in demanding environments.

• Three-pole configuration.
• Current rating of sixty amps.
• Interrupt rating of eighteen kiloamperes at four hundred eighty volts.

Product Highlights

This circuit breaker is suitable for protecting electrical circuits in diverse installations. It helps in reducing the risk of arc flash incidents, ensuring the safety of employees and equipment.

Product Information

Standard Information

• Brand: Eaton
• MPN: PDG13C0060TFFJ

Technical Specifications

• Catalog Number: PDG13C0060TFFJ
• Manufacturer: Eaton
• Frame: 1
• Current Rating: 60 A
• Interrupt Rating: 18 kAIC at 480 Vac
• Number of Poles: 3
• Voltage Rating: 600 Vac
• Trip Type: T-M (Fxd-Fxd) TU
• Made in USA: No
• Country of Origin: Dominican Republic
• Weight: 1.36 kg
• Height: 139.7 mm
• Length: 76 mm
