Eaton PDG13C0025TFFJ Power Defense PD 25A Circuit Breaker

Product Description

Eaton Power Defense PDG13C0025TFFJ is a molded case circuit breaker with a current rating of twenty-five amps. Designed for global applications, it combines a small footprint with robust performance. This three-pole breaker can handle voltages up to six hundred volts and is equipped with T-M trip units that help manage arc flash risks.

• Globally rated for diverse applications.
• Interrupt rating of eighteen kiloamperes at four hundred eighty volts.
• Standard line and load terminal type.

Product Highlights

This circuit breaker provides advanced protection and is ideal for various applications, including mobile machinery and factory equipment.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: Eaton

Technical Specifications

• Catalog Number: PDG13C0025TFFJ
• Current Rating: 25 A
• Voltage Rating: 600 Vac
• Number of Poles: 3
• Interrupt Rating: 18 kAIC at 480 Vac
• Frame: 1
• Trip Type: T-M (Fxd-Fxd) TU
• Country of Origin: Dominican Republic
