Product Description
The Eaton PCC-2-R is a subminiature fast acting fuse designed for high voltage DC applications. This fuse is UL recognized for its capability to provide overcurrent protection. Featuring a current rating of two amperes and a voltage rating of two hundred fifty VAC and four hundred fifty VDC, it offers reliable performance in various electrical configurations.
- Radial lead terminal for easy mounting
- Features a maximum interrupt rating of fifty to five thousand nine hundred amps
- Non-indicating and ideal for equipment protection
Product Highlights
This product is essential for protecting sensitive components or internal circuits within equipment. It ensures safety and functionality in various electrical systems.
Product Information
Standard Information
-
Manufacturer: Eaton
-
Brand Name: Bussmann
Technical Specifications
-
Amperage Rating: 2 A
-
Application: High Voltage DC Applications
-
Body Size: 0.29 in H x 0.3 in W x 0.095 in D
-
Indicating: Non-Indicating
-
Manufacturer Part Number: PCC-2-R
-
Mounting Type: Through Hole
-
Response Time: 4 hr, 10 s
-
Series: PCC
-
Standards/Approvals: RoHS Compliant, CSA File No. 053787, RoHS 2002/95/EC, UL File No. E19180 Recognized, CSA 42731
-
Terminal Type: Radial Lead
-
Type: Subminiature
-
Voltage Rating: 250 VAC, 450 VDC
