Eaton NOS-45 Bussmann Series One-time Fuse 45 A (1.05 in x 5.5 in)

Product Description

Eaton NOS-45 is a Bussmann Series Class K5 one-time, non-current-limiting fuse rated 45 A with a 600 Vac voltage rating and a 50 kA interrupting rating. The cylindrical melamine body measures approximately 1.05 in diameter by 5.50 in length and uses ferrule end connections for holder mounting. It is a single-element, general-purpose fuse intended for light-duty branch circuits, safety, and security system applications.

• 45 A ampere rating, 600 Vac voltage rating, 50 kA interrupting rating
• One-time, non-current-limiting (Class K5) design with single element
• Cylindrical melamine body (1.05 in x 5.50 in) with ferrule end terminals and holder mount

Product Highlights

45 A Bussmann one-time fuse, 600 Vac, 50 kA interrupting rating, ferrule ends, 1.05 in x 5.50 in

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: NOS-45

Technical Specifications

• Brand: Eaton
• Manufacturer Part Number: NOS-45
• Series: Bussmann Series (NOS)
• Type: One-time, non-current-limiting fuse
• Fuse Class: Class K5
• Amperage Rating: 45 A
• Voltage Rating: 600 VAC
• Interrupting Rating: 50 kA at 600 Vac
• Body Size / Dimensions: 1.05 in diameter x 5.50 in length
• Body Type: Cylindrical
• Material: Melamine
• Terminal Type: Ferrule
• Connection: Ferrule end x ferrule end
• Mounting Type: Holder mount
• Element: Single
• Standards/Approvals: CE; CSA 1421-01/File No. 53787; UL 248-9; UL File No. E4273; UL Guide JDDZ
• Application: Light duty circuit locations; safety and security systems
• Weight: 0.25 lb
• Packaging Quantity: 10
