Eaton NON-5 BUS FUSE 250V FUSE OT5SHW (1)

Product Description

The Eaton NON-5 is a Bussmann one-time general purpose fast acting non-current limiting fuse. This fuse is designed to protect lighting, heating, and other circuits that are not subject to temporary surges. It operates at an amperage rating of five and can handle voltages up to 250 VAC or 125 VDC.

• Single element, cylindrical body design
• Suitable for industrial and light duty circuit applications
• Rejection type fuse with a 50 kAIC interrupt rating

Product Highlights

This fuse is ideal for applications in industrial facilities and safety systems. It features a holder mount and ferrule end terminal for easy installation.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: NON-5

Technical Specifications

• Amperage Rating: 5 A
• Voltage Rating: 250 VAC / 125 VDC
• Body Size: 0.56 in Dia x 2 in L
• Body Type: Cylindrical
• Class: H
• Material: Melamine
• Mounting Type: Holder
• Element: Single
• Terminal Type: Ferrule End
• Standards/Approvals: CE Certified, CSA Class 1421-01, UL 248-9
• Rejection Type: Rejection
