Eaton NON-2 Buss 250V Fuse OT2SHW (1)

Product Description

The Eaton NON-2 Buss Fuse is a one-time, general purpose fast acting fuse with a 2 A rating. It operates at a voltage of two hundred fifty volts alternating current and one hundred twenty-five volts direct current. This fuse is designed to provide protection for electrical circuits that do not experience temporary surges. It should be used in applications where the available short circuit currents are low.

• Voltage rating: 250 VAC/125 VDC
• Interrupting rating: 50 kAIC
• Body size: 0.56 inches diameter by 2 inches length

Product Highlights

This fuse type is non-current limiting and should not be used in circuits with large transients or motor overloads. It features a cylindrical body made of melamine and a ferrule end terminal for easy installation.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: NON-2

Technical Specifications

• Amperage Rating: 2 A
• Application: Industrial facilities, safety systems
• Body Size: 0.56 in diameter x 2 in length
• Body Type: Cylindrical
• Class: H
• Element: Single
• Material: Melamine
• Mounting Type: Holder
• Terminal Type: Ferrule End
• Voltage Rating: 250 VAC/125 VDC
