Product Description
Bussmann NON-150 fuse is a one-time non-current limiting fuse designed for circuit protection. This fuse has a rating of one hundred fifty amperes at two hundred fifty volts AC with a ten kAIC interrupt capacity. It features a blade end terminal with a holder mount and is constructed of melamine. The overall body size is one point five six inches in diameter and seven point one three inches in length.
- Provides circuit protection for various applications.
- Designed for light duty circuit locations and safety systems.
- Easy to install with holder mount.
Product Highlights
This fuse is ideal for protecting lighting, heating, and circuits with low available short circuit currents. It has no appreciable time delay, making it unsuitable for circuits with significant transients or motor overloads.
Product Information
Standard Information
-
Manufacturer: Eaton
-
UPC: 05171210170
Technical Specifications
-
Amperage Rating: 150 A
-
Voltage Rating: 250 VAC
-
Body Size: 1.56 in Dia x 7.13 in L
-
Body Type: Cartridge
-
Class: H
-
Material: Melamine
-
Terminal Type: Blade End
-
Element: Single
