Eaton NDN111-WH Bussmann Terminal Block 600 V 90 A 3 Poles DIN Rail Mount

Product Description

The Eaton NDN111-WH Bussmann terminal block is a reliable solution for electrical connections. It operates at 600 volts and has a current rating of 90 amps. This terminal block supports wire sizes from eighteen to two American wire gauge. It has three poles and mounts easily to DIN rails.

• Designed for stationary machine equipment in factory robotics.
• Terminates with a #1/4-28 screw for secure connections.
• Features thermoplastic material for durability and heat resistance.

Product Highlights

This terminal block provides a low-cost solution with easy installation and efficiency in electrical setups.

Product Information

Standard Information

• Manufacturer: Eaton
• Model Number: NDN111-WH

Technical Specifications

• Amperage Rating: 90 A
• Voltage Rating: 600 V
• Wire Size: 18 to 2 AWG
• Number of Poles: 3
• Spacing: 16.31 mm
• Torque Rating: 32 in-lb
• Temperature Rating: 105 deg C
• Mounting Type: DIN Rail
• Connection Type: #1/4-28 Screw
• Material: Thermoplastic
• Standards/Approvals: CSA File 47235, RoHS Compliant, UL File No. E62622, UL94 V-2 Flammability Rating
• Dimensions: 1.87 in W x 1.44 in D x 1.71 in H
