Eaton NBH5-E-2-4 Rod to Beam Hanger Flange

Product Description

The EATON NBH5-E-2-4 is a rod-to-beam hanger flange from the B-Line series of threaded rod and drop wire supports. This fitting connects a threaded rod to a beam flange, suspending conduit, pipe, duct, or cable tray from structural steel in commercial and industrial installations. It accepts rod sizes from 0.25 inches to 0.38 inches and supports a rated load capacity of 160 pounds. The overall footprint is compact at 1 inch height, 1 inch length, and 1 inch width, with a package weight of 0.062 pounds. Nuts are required for installation and are sold separately — refer to rod beam clamp CA6TA24 for compatible hardware.

This hanger flange is suited for use in commercial construction, industrial facilities, and mechanical rooms where threaded rod suspension systems are used to support piping, conduit, or HVAC components. It is designed for beam flanges with a mounting thickness ranging from 0.13 inches minimum to 0.25 inches maximum. Electrical contractors, pipefitters, and mechanical contractors typically specify B-Line series hangers for code-compliant suspended support systems.

Key Features

• Rated load capacity of 160 pounds for reliable overhead support
• Compatible with rod sizes from 0.25 inches to 0.38 inches
• Flange mount thickness range: 0.13 inches minimum to 0.25 inches maximum
• Compact 1 inch x 1 inch x 1 inch profile fits tight overhead spaces
• Part of the B-Line series for consistent compatibility across threaded rod support systems
• Nuts required — compatible with rod beam clamp CA6TA24

Compatibility

Designed as an OEM-style component within the EATON B-Line series threaded rod and drop wire support system. Compatible nuts and hardware referenced as rod beam clamp CA6TA24.

Installation Notes

Installation is typically performed by licensed electricians, pipefitters, or mechanical contractors in accordance with applicable building and mechanical codes. De-energize and lock out any nearby electrical systems before working overhead. Ensure the beam flange thickness falls within the 0.13 inch to 0.25 inch mounting range before securing. Nuts are not included and must be sourced separately — do not exceed the 160-pound rated load capacity.

Technical Specifications

• Height: 1 inch
• Length: 1 inch
• Width: 1 inch
• Weight: 0.062 pounds
• Rod Size Range: 0.25 inches to 0.38 inches
• Mount Size Range: 0.13 inches minimum to 0.25 inches maximum
• Load Capacity: 160 pounds
• Series: B-Line
• Type: Rod to Beam Hanger Flange
• UPC: 781011190200

Standard Information

• Brand: EATON
• Manufacturer Part Number: NBH5-E-2-4
