Eaton M22S-ST-GB1 Selector Switch Label Plate

Product Description

The EATON M22S-ST-GB1 is a label plate accessory designed for use with 22.5mm modular selector switches and pushbutton operator assemblies. It mounts to the front face of compatible M22 series control devices, providing a clean, professional marking surface for panel labeling and operator identification. Electricians and panel builders use this type of label plate during control panel assembly to meet identification requirements and improve operator clarity on industrial and commercial equipment. At 0.043 pounds, it is a lightweight component suited for high-volume panel builds.

This label plate fits into the M22 series 22.5mm mounting footprint, making it appropriate for use in industrial control panels, machine operator interfaces, and commercial electrical enclosures. It is typically installed during panel fabrication or retrofit labeling upgrades where clear operator identification is required on selector switches, pushbuttons, or pilot devices.

Key Features

• Designed for 22.5mm modular selector switch and pushbutton operator assemblies
• Lightweight construction at 0.043 pounds for easy panel integration
• Part of the EATON M22 series modular control device system
• Provides front-face operator identification and panel labeling surface

Compatibility

Designed as an OEM-style accessory label plate for 22.5mm modular pushbutton and selector switch assemblies in the EATON M22 series product family.

Installation Notes

Installation of this label plate should be performed by a qualified electrician in accordance with NEC requirements and applicable local codes. De-energize the control panel and follow lockout/tagout procedures before working inside any electrical enclosure. The label plate snaps or clips onto the operator device front face as part of panel assembly. Verify fit and seating before returning the enclosure to service.

Technical Specifications

• Mounting Size: 22.5mm
• Weight: 0.043 pounds
• UPC: 78668527731

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22S-ST-GB1
