Eaton M22-XST-D12 22.5mm Selector Switch Actuator

Product Description

The EATON M22-XST-D12 is a selector switch actuator designed for use in the M22 modular control component series. Built to the 22.5 mm form factor standard, this actuator serves as the operator interface element that mounts to a compatible M22 base or contact block assembly. It is intended for panel-mount control applications where a rotary selector input is required. Electricians and control panel builders install this type of component in industrial and commercial electrical enclosures to provide reliable manual switching control.

The M22-XST-D12 is suited for use in control panels, machine tool enclosures, and industrial automation cabinets. It fits into standard 22.5 mm cutout mounting holes, making it compatible with the broader M22 product family of actuators, bases, and contact blocks. This actuator is appropriate for both new panel builds and replacement of worn or damaged selector switch operators in existing installations.

Key Features

• 22.5 mm mounting diameter fits standard panel cutouts
• Part of the M22 modular system, allowing pairing with compatible contact blocks and bases
• Compact profile at approximately 1.0 x 1.0 x 0.5 inches overall envelope
• Lightweight construction at approximately 0.01 pounds
• Designed for straightforward panel-mount installation

Compatibility

Designed for use within the EATON M22 modular selector switch system, compatible with 22.5 mm format M22 series bases and contact block assemblies.

Installation Notes

Installation is performed by a qualified electrician. De-energize and lock out the panel before installing or replacing any control operator component. The actuator mounts through a standard 22.5 mm panel cutout and secures to the appropriate M22 base or contact block per the assembly instructions. Work must comply with applicable NEC requirements for industrial control panels.

Technical Specifications

• Mounting Size: 22.5 mm
• Dimensions (L x W x H): 1.0 x 1.0 x 0.5 inches
• Weight: 0.01 pounds
• UPC: 78668527726

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22-XST-D12
