Description

Product Description

The Eaton M22-XL-R is a lens from the M22 line of 22 mm IEC pushbuttons suitable for machine control applications. Designed for OEMs, end users, and system integrators, it offers front panel aesthetics and flexibility. It is ideal for applications needing high pressure and high-temperature washdown applications.

  • Impact-resistant polycarbonate enclosures
  • Aesthetic design increases perceived machine value
  • Anti-rotation tab and central nut mount for easy installation

Product Highlights

The M22 lens features a heavy-duty design, secure connections, and communication connectivity via USB or RJ45 interfaces.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: M22-XL-R
Technical Specifications
Color
Red
Series
RMQ-Titan M22
Type
Lens
Size
22.5 mm
NEMA Rating
NEMA 4X/21/IP67/IP69K
Shape
Round
Legend
Blank
Material
Plastic
Product Name
Eaton M22 pushbutton light lens
Catalog Number
M22-XL-R
UPC
786685278759
Product Length/Depth
29 mm
Product Height
9 mm
Product Width
29 mm
Product Weight
0.002 kg
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
GoST-R Bureau Veritas CE Marked
Certifications
CSA Certified CCC Marked Lloyd's Register Certified
Catalog Notes
Minimum order quantity of 10
Product Type
Pushbutton accessory
Button color
Red
Illumination
Illuminated
Mounting method
Flush
Environmental rating
IP67, IP69K, NEMA 4X, NEMA 21
Model Code
M22-XL-R
EAN
4015082164546
Global Catalog
216454
Used with
M22-LC-X M22-L-X
10.10 Temperature rise
Not applicable.
10.11 Short-circuit rating
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function
The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10.2.2 Corrosion resistance
Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures
Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat
Meets the product standard's requirements.
10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects
Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation
Please enquire
10.2.5 Lifting
Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact
Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions
Meets the product standard's requirements.
10.3 Degree of protection of assemblies
Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances
Meets the product standard's requirements.
10.5 Protection against electric shock
Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components
Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections
Is the panel builder's responsibility.
10.8 Connections for external conductors
Is the panel builder's responsibility.
10.9.2 Power-frequency electric strength
Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage
Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material
Is the panel builder's responsibility.
Connection to SmartWire-DT
No
Ambient operating temperature - max
70 °C
Ambient operating temperature - min
-25 °C
Built-in diameter
22.5 mm
Equipment heat dissipation, current-dependent Pvid
0 W
Heat dissipation capacity Pdiss
0 W
Heat dissipation per pole, current-dependent Pvid
0 W
Rated operational current for specified heat dissipation (In)
0 A
Static heat dissipation, non-current-dependent Pvs
0 W
Product category
Accessories
Diameter
29.6 mm
Lens color
Red
Design
Flush Flat
Inscription
Individual inscription possible: > 5 characters: letter height 3 mm Individual inscription possible: ≤ 5 characters: letter height 5 mm
Inscription type
Blank
Lens shape
Round
(Switching-Indication) NEMA Rating
NEMA 21
Component
Push Button
(Switching-Indication) Size
22.5 mm
Manufacturer
Eaton
Actuator
Flush
Etching code
Custom
Family Series
Eaton Switches
Net Weight
0.005 lbs
Gross Weight
0.05 lbs
