Eaton M22-R47K 47K Ohm Potentiometer Panel Mount

Product Description

The EATON M22-R47K is a 47K ohm panel-mount potentiometer designed for industrial control applications. It functions as a variable resistor, allowing operators or control systems to adjust signal output by rotating a shaft or knob. This type of component is commonly wired into control panels, motor drive circuits, and process control systems where continuous analog adjustment is required. Electricians and industrial control technicians install this device as part of operator interface stations or control enclosures. At 0.068 pounds, the M22-R47K is a compact, lightweight unit suited for standard panel cutout mounting.

This potentiometer is appropriate for use in industrial and commercial control panel installations where a 47K ohm variable resistor is specified. It fits into systems requiring manual setpoint adjustment, speed reference input, or signal scaling. The M22 series form factor is a common standard in industrial control panel design, making this unit a practical fit for new builds and retrofit projects alike.

Key Features

• 47K ohm resistance value for compatible analog control circuits
• Panel-mount design for direct integration into control enclosures and operator stations
• Compact, lightweight construction at 0.068 pounds
• Compatible with standard M22 series panel cutout dimensions
• Suitable for motor drive speed reference, setpoint adjustment, and signal scaling applications

Compatibility

Designed as an OEM-style replacement or new-installation potentiometer for industrial control panels utilizing M22 series panel-mount components.

Installation Notes

Installation should be performed by a qualified electrician or industrial controls technician. De-energize the control panel and verify the absence of voltage before beginning any wiring work, following applicable NEC guidelines. Secure the potentiometer in the panel cutout per the manufacturer's mounting instructions before making electrical connections. Verify that the resistance value and wiring configuration match the control system schematic before restoring power.

Technical Specifications

• Resistance: 47K ohm
• Weight: 0.068 pounds
• UPC: 78668527677

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22-R47K
