Eaton M22-L-B-B Flush Pushbutton Actuator 22.5 Mm

Product Description

The EATON M22-L-B-B is a flush-type pushbutton actuator designed for use in industrial and commercial control panel applications. This 22.5 mm actuator mounts to standard 22.5 mm cutout enclosures and operator interfaces, providing a low-profile, flush button surface that minimizes the risk of accidental activation. It is intended for use with EATON M22 series contact blocks and accessories. Electricians and control panel technicians install this actuator as part of motor control, machine safety, or process control circuits.

This actuator is suited for panel-mount applications in light industrial, commercial, and HVAC electrical control systems. The flush-button design is appropriate for environments where inadvertent contact with protruding operators is a concern. It pairs with the broader EATON M22 series modular component system, allowing technicians to assemble custom operator configurations using compatible contact blocks, LED modules, and holders.

Key Features

• Flush-type actuator design reduces risk of accidental operation
• 22.5 mm mounting footprint fits standard M22 series panel cutouts
• Modular design compatible with EATON M22 series contact blocks and accessories
• Compact form factor suitable for dense control panel layouts
• Weighs 0.05 pounds for minimal load on panel assemblies

Compatibility

Designed for use with the EATON M22 series modular pushbutton system using a 22.5 mm panel cutout. Specific compatible contact blocks or holders were not identified in the available product data; consult EATON M22 series documentation to confirm compatible accessories.

Installation Notes

Installation is typically performed by a licensed electrician. De-energize all control circuits and lock out the panel before disassembling or installing any operator components. The actuator mounts through the panel cutout and secures with the corresponding M22 series holder or base; do not force or over-tighten retaining hardware. Follow applicable NEC requirements for control panel wiring and enclosure ratings.

Technical Specifications

• Mounting Size: 22.5 mm
• Actuator Style: Flush Type
• Package Dimensions (L x W x H): 7 inches x 5 inches x 1.5 inches
• Weight: 0.05 pounds
• UPC: 78668527854

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22-L-B-B
