Eaton LPN-RK-250SP LPN-RK Time Delay Fuse 250 A (1 Each)

Product Description

Eaton LPN-RK-250SP is a Bussmann LPN-RK series dual-element, time-delay, current-limiting fuse rated 250 A and 250 V AC/DC. It provides high interrupting capacity (300 kA AC, 100 kA DC) and a 10 second time delay at 500% rated current for selective coordination. The cartridge-style fuse features blade end terminals and a melamine body (2.36 in diameter x 8.63 in length) for use in switchboards, panelboards, motor control centers, and feeder circuits.

• 250 A, 250 V AC/DC; Class RK1 time-delay, dual-element, current-limiting design
• Interrupting rating 300 kA (AC) and 100 kA (DC); 10 s time delay at 500% rated current
• Cartridge body 2.36 in dia x 8.63 in L with blade end terminals; melamine construction; holder mount

Product Highlights

Class RK1 250 A time-delay fuse for motor, feeder, and distribution protection

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: LPN-RK-250SP
• Country of Origin: Mexico

Technical Specifications

• Brand: Eaton
• Manufacturer Part Number: LPN-RK-250SP
• Series: LPN-RK
• Type: Time-delay, current-limiting fuse
• Class: RK1
• Current Rating: 250 A
• Voltage Rating: 250 V AC/DC
• Interrupting Rating: 300 kA (AC), 100 kA (DC)
• Time Delay: 10 s at 500% rated current
• Element: Dual element
• Indicating: Non-indicating
• Terminal Type: Blade end
• Mounting Type: Holder
• Body Type: Cartridge
• Dimensions: 2.36 in diameter x 8.63 in length
• Material: Melamine
• Weight: 1.75 lb
• Applications: Large distribution switchboards, power panelboards, motor control centers, machinery disconnect switches, feeder and branch circuits, motors, transformers, solenoids, general-purpose circuits
• Approvals/Certifications: UL; CSA C22.2; CE; RoHS Compliant
• UPC: 051712538527
• Country of Origin: Mexico
• Series Coverage: LPN-RK 70-600A
