Eaton LP-CC-4-1/2 Bussmann Series LP-CC-4-1/2 Low Peak Time Delay Fuse

Product Description

Eaton Bussmann Series LP-CC-4-1/2 is a low peak time delay fuse. It is a current-limiting, non-indicating fuse with a ferrule end design. This fuse operates at 4.5 amps with a voltage rating of 600 volts AC and 150 volts DC. Its interrupt rating is 20 kAIC at 150 VDC and 200 kAIC at 600 VAC. This fuse is suitable for specialized circuits, industrial control, and safety systems.

• Time delay feature reduces nuisance blowing during surge conditions.
• Compact size measuring thirteen thirty-seconds inches in diameter by one and a half inches long.
• Meets NEC section 110.9 for large capacity systems.

Product Highlights

This fuse provides superior protection for small motors and minimizes spare inventory needs.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: LP-CC-4-1/2

Technical Specifications

• Amperage Rating: 4.5 A
• Voltage Rating: 600 VAC/150 VDC
• Body Size: 13/32 inches in diameter x 1-1/2 inches long
• Body Type: Cartridge
• Class: CC
• Response Time: 12 seconds at 200%
• Terminal Type: Ferrule
• Material: Melamine
