Eaton LP-CC-1-6/10 BUS LOW PEAK CLASS CC FUSE

Product Description

The Eaton LP-CC-1-6/10 BUS LOW PEAK CLASS CC FUSE is designed for current limiting protection. This fuse operates at a rating of 1.6 amperes and supports a voltage rating of six hundred volts alternating current and three hundred volts direct current. The fuse offers a unique time delay feature that helps prevent unwanted openings during surge conditions.

• Suitable for circuits requiring time delay or fast-acting protection.
• Compact size with dimensions of thirteen thirty-seconds of an inch diameter by one and a half inches in length.
• Complies with NEC section 110.9 for high-capacity systems.

Product Highlights

This fuse is recognized in the industry for its reliability and efficiency, providing upgraded protection while reducing inventory needs.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: LP-CC-1-6/10

Technical Specifications

• Amperage Rating: 1.6 A
• Voltage Rating: 600 VAC / 300 VDC
• Interrupt Rating: 20 / 200 kA
• Response Time: 12 s at 200%
• Body Size: 13/32 in Dia x 1-1/2 in L
• Body Type: Cartridge
• Material: Melamine
• Mounting Type: Holder
