Eaton LP-CC-1-1/8 Bussmann Series Low Peak Time Delay Fuse

Product Description

The Eaton Bussmann Series LP-CC-1-1/8 is a low peak time delay fuse designed for current limiting applications. This fuse features a current rating of 1.125 Amps and is suitable for use in both AC and DC circuits with voltages up to 600 VAC and 300 VDC.

• Current limiting time-delay functionality
• Ferrule end terminals for easy installation
• Designed for specialized circuits and industrial controls

Product Highlights

This fuse provides superior protection for motor circuits, effectively limiting currents and reducing inventory costs with upgraded Low-Peak fuses.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Bussmann Mfg.

Technical Specifications

• MPN: LP-CC-1-1/8
• Type: Current Limiting Time Delay
• Amperage Rating: 1.125 A
• Voltage Rating: 600 VAC / 300 VDC
• Interrupt Rating: 200 kAIC at 600 V, 20 kAIC at 300 VDC
• Response Time: 12 seconds at 200%
• Body Size: 13/32 inches diameter x 1-1/2 inches length
• Material: Melamine
• Application: Specialized Circuits, Industrial Control
