Eaton KTK-R-6/10 Midget Fuse 6/10 Amp 600V

Product Description

The EATON KTK-R-6/10 is a current-limiting, fast-acting midget fuse rated at 6/10 amp and 600 volts AC. Manufactured under the Bussmann series, this Class CC fuse is designed to provide branch-circuit and control-circuit protection in compact fuseholder assemblies. Its rejection-style end caps prevent substitution with lower-rated fuse classes, maintaining system integrity. Licensed electricians and control-panel technicians install this fuse in industrial control panels, HVAC equipment, and other electrical systems where space constraints require a 13/32 inch by 1-1/2 inch form factor.

The KTK-R-6/10 is suited for residential, commercial, and light industrial applications where reliable overload and short-circuit protection is required in tight enclosures. It fits standard 13/32 inch by 1-1/2 inch midget fuseholders and is commonly found protecting control transformers, small motors, and instrumentation circuits in HVAC systems and electrical control assemblies.

Key Features

• Current-limiting, fast-acting operation for quick fault clearing
• Class CC rejection-style end caps prevent installation of lower-rated fuse classes
• Rated 6/10 amp at 600 volts AC for branch and control circuit protection
• Compact 13/32 inch by 1-1/2 inch midget form factor fits space-constrained enclosures
• Bussmann series construction for consistent performance in control-panel applications

Compatibility

Designed as an OEM-style replacement midget fuse for Class CC fuseholders rated for 13/32 inch by 1-1/2 inch fuses in electrical control panels and HVAC equipment.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). Always de-energize and lockout/tagout the circuit before replacing any fuse. Verify the fuseholder is rated for Class CC fuses and confirm the replacement amperage matches the circuit protection requirements. Never substitute a fuse of a higher amperage rating than specified by the equipment manufacturer.

Technical Specifications

• Amperage Rating: 6/10 amp
• Voltage Rating: 600 volts AC
• Fuse Class: CC
• Response Type: Fast-acting, current-limiting
• Size: 13/32 inch by 1-1/2 inch
• UPC: 05171242050

Standard Information

• Brand: EATON
• Manufacturer Part Number: KTK-R-6/10
