Eaton KTK-R-1/4 Limitron Current-Limiting Fast-Acting Fuse 1/4 Amp (13/32 in Dia x 1-1/2 in L)

Product Description

The Eaton KTK-R-1/4 is a Bussmann Limitron current-limiting fast-acting fuse (MPN KTK-R-1/4) rated 0.25 A and 600 V. It uses a melamine tube construction with ferrule end x ferrule end terminations and a Class CC rejection style, providing a 200 kAIC interrupting rating. The cylindrical cartridge measures 13/32 in diameter by 1-1/2 in length and is used in industrial control, specialized circuits, inline fuse holders, and branch circuits.

• LIMITRON current-limiting, fast-acting design; Class CC, 0.25 A rating
• 600 V voltage rating with 200 kAIC interrupting capability
• Rejection style cartridge with ferrule end x ferrule end terminations; melamine tube; 13/32 in x 1-1/2 in

Product Highlights

Class CC Limitron fuse, 0.25 A, 600 V, 200 kAIC, melamine tube, ferrule terminations, rejection style

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: KTK-R-1/4
• Country of Origin: United States

Technical Specifications

• Brand: Eaton (Bussmann)
• Manufacturer: Bussmann Mfg.
• Manufacturer Part Number: KTK-R-1/4
• Series: KTK-R
• Product Type: LIMITRON current-limiting fast-acting fuse
• Current Rating: 0.25 A (1/4 A / 250 mA)
• Voltage Rating: 600 V
• Fuse Class: Class CC
• Interrupting Rating: 200 kAIC
• Tube Material: Melamine
• Terminations: Ferrule end x ferrule end
• Style: Rejection style (Class CC rejection)
• Dimensions: 13/32 in diameter x 1-1/2 in length (0.40625 in x 1.5 in)
• Body Type: Cylindrical cartridge
• Mounting Type: Holder / clip-mounted
• Typical Applications: Industrial control panels and machinery; inline fuse holders; branch circuits; specialized circuits
• Material: Melamine tube with nickel-plated bronze end caps (reported)
• Weight: 0.016 lb (reported)
• Certifications and Compliance: UL Listed; CSA Certified; CE Marked; RoHS Compliant
• GTIN / UPC: 00051712420549 / 051712420549
• Datasheet: https://www.eaton.com/content/dam/eaton/products/electrical-circuit-protection/fuses/bussmann-series-branch-circuit-fuses/class-cc/bus-ele-ds-1015-ktk-r.pdf
