Eaton KTK-R-1/10 BUS 600V Limitron Fuse

Product Description

Eaton KTK-R-1/10 is a Bussmann Limitron fuse designed for fast acting current limiting in low voltage applications. This fuse offers an amperage rating of zero point one amp and a voltage rating of six hundred volts AC. Its interrupt rating is two hundred kiloamperes, providing reliable protection for various electrical circuits.

• Current limiting at class CC levels for optimal short circuit protection
• 200 kA interrupt rating for high circuit ratings
• Class CC rejection feature to prevent incorrect fuse installations

Product Highlights

This fuse is suited for use in industrial and commercial settings where safety and reliability are key. It includes nickel plated bronze end caps for enhanced durability.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: KTK-R-1/10

Technical Specifications

• Amperage Rating: 0.1 A
• Voltage Rating: 600 VAC
• Body Size: 13/32 in Dia x 1-1/2 in L
• Element: Single
• Body Type: Cartridge
• Class: cc
• Rejection Type: Rejection
• Material: Melamine Tube
• Terminal Type: Ferrule End
• Mounting Type: Holder
• Standards/Approvals: CE Certified, CSA C22.2 File No. 53787/248.4, RoHS Compliant, UL 248-14 File No. E19180 Guide JDYX
