Eaton KTK-50 Midget Fuse 600V 50A

Product Description

The EATON KTK-50 is a 600-volt, 50-amp current-limiting midget fuse designed for protecting control circuits, motor circuits, and sensitive instrumentation from overloads and short-circuit conditions. This fast-acting fuse fits standard 13/32-inch by 1-1/2-inch midget fuse holders and is a common choice in control panels, HVAC equipment, and industrial machinery. Electricians and controls technicians install it where compact, high-interrupting-capacity overcurrent protection is required in tight panel spaces.

The KTK-50 is suited for residential and commercial control circuit applications where a midget-class fuse is specified. It is commonly found in HVAC control panels, machine tool circuits, and process control enclosures. The fast-acting response makes it appropriate for protecting semiconductor devices and other current-sensitive loads in low-voltage control wiring.

Key Features

• 600-volt AC rating suitable for standard control circuit voltages
• 50-amp current rating in a compact midget form factor
• Fast-acting response for protection of sensitive electronic and control components
• Fits standard 13/32 inch by 1-1/2 inch midget fuse holders
• Current-limiting design reduces let-through energy during fault conditions

Compatibility

Designed as an OEM-style replacement for standard 13/32 inch by 1-1/2 inch midget fuse holders used in control panels, HVAC equipment, and industrial control enclosures.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lockout/tagout the circuit before removing or installing any fuse. Verify that the replacement fuse matches the voltage and amperage rating specified on the equipment nameplate. Do not install a fuse with a higher ampere rating than the circuit is designed to carry.

Technical Specifications

• Voltage Rating: 600 volts AC
• Ampere Rating: 50 amps
• Fuse Class: Midget (KTK)
• UPC: 05171242034

Standard Information

• Brand: EATON
• Manufacturer Part Number: KTK-50
