Eaton JM60060-1CR BUS CLASS J FUSE BLOCK 600V 60A 1-POLE (1)

Product Description

Eaton's JM60060-1CR is a Bussmann class J fuse block designed for voltage ratings of 600 VAC and amperage ratings from thirty-one to sixty amps. It features a single pole design with box lug and slot screw connections suitable for various electrical applications. This fuse block is compatible with low-peak LPJ, Limitron JKS, and DFJ Ferrule fuses. The device is constructed from thermoplastic, ideal for installation on DIN rails or panels.

• Meets standards of UL and CSA for safety and reliability.
• Designed for use with 14 to 2 AWG copper and 8 to 2 AWG aluminum wire.
• Temperature rated from -40 to 120 degrees Celsius.

Product Highlights

Use this fuse block in electrical assemblies, panels, and OEM applications. Its modular design allows for quick assembly and enhances safety.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171251466

Technical Specifications

• Amperage Rating: 31 to 60 A
• Voltage Rating: 600 VAC
• Number of Poles: 1
• Class: J
• Dimensions: 4.7 inches L x 1.5 inches W x 2.6 inches H
• Fuse Length: 2.38 inches
• Fuse Diameter: 1.06 inches
• Mounting Type: DIN Rail/Panel
• Material: Thermoplastic
• Suitable For Use With: Low-Peak LPJ, Limitron JKS and DFJ Ferrule Fuse
• Standards/Approvals: UL File No. E14853, CSA File No. 47235, CE Certified
