Eaton JGH3250FAG Series G JG Frame Molded Case Circuit Breaker 250 Amp

Product Description

The Eaton JGH3250FAG Series G complete molded case circuit breaker, JG Frame, 250 A, Three-pole, 600V. It has a 100 kAIC at 240V, 70 kAIC at 415V, 65 kAIC at 480V, 25 kAIC at 600V interrupt rating. It comes with line/load standard w/ metric mounting hardware, Fixed thermal, and adjustable magnetic trip type. Suitable for electrical assemblies, panels and EOEMs.

• Fixed thermal, adjustable magnetic trip
• Line and load terminals
• Suitable for Elec Assemblies, Panels & EOEM

Product Highlights

The Eaton JGH3250FAG circuit breaker is a reliable solution for circuit protection needs. It offers adjustable settings and robust construction.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: JGH3250FAG

Technical Specifications

• Type: Complete Breaker
• Brand: Eaton
• Frame: JG-frame
• Width: 4.13 in
• Height: 4.13 Inch
• Length: 3.57 Inch
• Current: 250 Amp
• Voltage: 600 Volt
• Amperage: 250 Amp
• Frequency: 50-60 Hz
• Trip Type: Adjustable Magnetic,Fixed Thermal
• Applications: Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
• Terminal Type: Line And Load
• Product Series: G
• Number of Poles: 3 Pole
• Interrupt Rating: 100 kAIC
• Circuit Breaker Type: JG
• Product Name: Eaton Series G complete molded case circuit breaker
• Catalog Number: JGH3250FAG
• Product Length/Depth: 3.57 in
• Product Height: 4.13 in
• Product Width: 4.13 in
• Compliances: CE Marked
• Certifications: IEC Rated UL Listed CSA Certified
• Product Type: Molded case circuit breaker
• Amperage Rating: 250 A
• Voltage rating: 600 Vac
• Trip Time: 50 ms
• Circuit breaker frame type: Complete breaker
• Rating: 80% rated
• Series: Series G
• Terminals: Line and load
• Frame Type: JG Frame
• Frequency rating: 50 to 60 Hz
• Mounting hardware: Metric
• Interrupt rating: 65 kAIC at 480 Vac 25 kAIC at 600 Vac 100 kAIC at 240 Vac
• Mounting Type: Panel Mount
• Actuator Type: Toggle
• UNSPSC Code: 39120000
• Current Rating: 250 A
• Voltage Rating: 600 VAC
