The Eaton JGE3200FAG is a Series G molded case circuit breaker with a JG frame. This three-pole, 200A circuit breaker operates at 600 Vac and is 80% rated. It has a fixed thermal, adjustable magnetic trip and is suitable for line and load applications. Designed for global use and integrates easily into Eaton switchboards and panelboards.

  • Fixed thermal, adjustable magnetic trip
  • Suitable for line and load applications
  • UL, CSA, CE, IEC and KEMA KEUR listings

Product Highlights

The Eaton Series G circuit breakers provide increased performance in a compact design. It is UL listed and IEC rated.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: JGE3200FAG
Technical Specifications
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGE3200FAG
UPC
782113526720
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Compliances
CE Marked
Certifications
CSA Certified UL Listed IEC Rated
Product Type
Molded case circuit breaker
Amperage Rating
200 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
80% rated
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50 to 60 Hz
Mounting hardware
Metric
Interrupt rating
18 kAIC at 600 Vac 65 kAIC at 240 Vac 25 kAIC at 480 Vac
Number of poles
Three-pole
Type
Complete breaker
Manufacturer
Eaton
Product Series
JG
Family Series
Eaton Circuit Breakers, JG Series
Description
Circuit Breaker, 3-P, 200A/600V, 25KAIC@480V, FIXED THERMAL, ADJ MAG. INCLft.S LINE AND LOAD TERMINALS
Poles
3
Current Rating
200 A
Max Voltage
600 VAC
Trip Unit
Fixed Thermal / Adj. Magnetic
Electronic Trip Unit
Optional
Mounting
Panel
Neutral Pole
No
Neutral Protection
No
100% Rated
No
Auxiliary Switch
Optional
Shunt Trip
Optional
Undervoltage Release
Optional
Alarm Switch
Optional
UL Standard
489
Volts AC
600
Interrupt Rating AC
18 kA
Voltage Rating VDC
250V
Voltage Rating VAC
600V
Circuit Breaker Mounting
DIN Rail, Panel
SVHC
No SVHC (17-Dec-2015)
Amperage
200A
Voltage
240VAC, 480VAC, 600VAC, 250VDC
Phase
3
AIC Rating
65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC
Mounting Style
Unit Mount
Terminal Type
Lugs
For Use With
Eaton Series G Panelboards, Switchboards, Motor Control Centers
Trip Technology
Thermal Magnetic
Trip Function Code
LI
Trip Function
Long-Time, Instantaneous
Trip Adjustability
Fixed Thermal, Adjustable Magnetic
Wire Gauge
8 AWG - 350 kcmil (Al/Cu)
Max Wire
350 kcmil
Min Wire
8 AWG
Available Options
Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Handle Mechanism, Motor Operator
Accessories
Line and Load Terminals (TA250FJ), Metric Mounting Hardware
Standards
CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489
Approval
CE, CSA, HACR, IEC, KEMA, UL
Temp Rating
40C
Construction Features
80% Rated, HACR Rated
