Eaton JGE3150FAG Type JGE Molded Case Circuit Breaker 600 VAC 150 A 18/25/65 kA Interrupt 3 Poles

Product Description

Eaton offers the JGE3150FAG, a series G molded case circuit breaker designed for effective circuit protection. This three-pole circuit breaker has a current rating of one hundred fifty amps and is suitable for use with voltages up to six hundred volts AC. It features fixed thermal and adjustable magnetic trip types, ensuring reliable operation across various applications.

• High interrupt ratings: 65 kA at 240 Vac, 25 kA at 480 Vac, and 18 kA at 600 Vac.
• Designed for ease of use, allowing for simple adjustments and field configurations.
• Compact dimensions support efficient use of space in electrical panels.

Product Highlights

The Eaton JGE3150FAG circuit breaker is engineered for global application, supporting numerous industrial and commercial needs with various trip configurations available.

Product Information

Standard Information

• Brand: Eaton
• Model: JGE3150FAG

Technical Specifications

• Amperage Rating: 150 A
• Voltage Rating: 600 Vac
• Frequency Rating: 50/60 Hz
• Dimensions: 9-1/2 inches x 5 inches x 6-1/2 inches
• Frame Type: JG
• Number of Poles: 3
• Interrupt Ratings: 65 kA at 240 Vac, 25 kA at 480 Vac, 18 kA at 600 Vac
• Country of Origin: Dominican Republic
