Product Description
The Eaton HTB-66I Buss Fuseholder is designed for high-temperature applications. It operates at two hundred fifty volts alternating current (VAC) and can handle amperages of sixteen to twenty amperes. This fuseholder is suitable for use with HTB series fuses and features a quick-connect design.
- Flame retardant construction
- Temperature range from negative fifty-five to eighty-five degrees Celsius
- Front panel hex nut mounting
Product Highlights
This product provides reliable connection and protection in electrical circuits, suitable for various applications requiring in-line fusing.
Product Information
Standard Information
-
Manufacturer: Eaton
-
UPC: 05171213634
Technical Specifications
-
Amperage Rating: 16/20 A
-
Color: Black
-
Connection Type: Quick-Connect
-
Dimensions: 0.94 in L
-
Fuse Diameter: 1/4 in
-
Fuse Length: 1-1/4 in
-
Material: Thermoplastic
-
Mounting Type: Front Panel Hex Nut
-
Number of Poles: 1
-
Series: HTB
-
Temperature Rating: -55 to 85 deg C
-
Voltage Rating: 250 VAC
-
Standards/Approvals: CE Certified, CSA Class 6225-01, UL Recognized, UL 94V0 Flammability Rating
-
Suitable For Use With: HTB Series Fuse
