Eaton hom250 50A Double Pole Miniature Circuit Breaker

Product Description

The EATON hom250 is a double-pole miniature circuit breaker rated for 50 amps at 120/240 volts AC. It is part of the Homeline series, engineered for plug-in installation into Homeline load centers. The breaker delivers standard overcurrent protection with a 10 kA interrupting capacity and is HACR rated, making it suitable for heating, air conditioning, and refrigeration circuits. Box lug terminals accept one conductor in the range of 8 AWG to 2 AWG, compatible with both copper and aluminum wire. Licensed electricians install this breaker during new construction, panel upgrades, or circuit replacement work.

The hom250 is designed for residential electrical distribution panels. Its plug-in mounting method speeds installation in Homeline load centers. The 50-amp, two-pole configuration suits high-load branch circuits such as electric ranges, dryers, HVAC equipment, water heaters, and subpanel feeds commonly found in residential and light commercial applications.

Key Features

• 50-amp, double-pole rating at 120/240 volts AC
• 10 kA interrupting capacity for standard residential fault protection
• HACR rated for heating, air conditioning, and refrigeration loads
• Plug-in mounting for fast installation in Homeline load centers
• Box lug terminals accept 8 AWG to 2 AWG copper or aluminum conductors
• UL Listed

Compatibility

Designed as a plug-in replacement for use in Eaton Homeline load centers and panels that accept Homeline-series miniature circuit breakers.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the panel and verify absence of voltage before handling any breaker or wiring. Ensure the wire gauge and material match the terminal rating before terminating conductors. Do not exceed the listed conductor range of 8 AWG to 2 AWG at the box lug terminals.

Technical Specifications

• Amperage: 50 amps
• Voltage: 120/240 volts AC
• Number of Poles: 2
• Interrupting Capacity: 10 kA
• Mounting Type: Plug-in
• Terminal Type: Box lug
• Wire Range: 8 AWG to 2 AWG copper or aluminum
• Height: 3.13 inches
• Width: 2.0 inches
• Depth: 2.98 inches
• Certifications: UL Listed, HACR Rated

Standard Information

• Brand: EATON
• Manufacturer Part Number: hom250
