EATON HMCP100R3CU62 C Series HMCP Motor Circuit Protector, 600 VAC, 250 VDC, 100 A, 3 Poles, Magnetic Trip

Product Description

EATON offers the HMCP100R3CU62, a C Series Motor Circuit Protector designed to provide reliable short-circuit protection for motors. This device operates at six hundred volts alternating current (VAC) and two hundred fifty volts direct current (VDC) with a capacity of one hundred amperes. The HMCP100R3CU62 features three poles and utilizes a magnetic trip mechanism.

• UL recognized instantaneous-only breaker for effective short-circuit protection.
• Can be integrated into tested motor starter combinations for complete UL Listed motor control.
• Suitable for current ratings ranging from three to one thousand two hundred amperes.

Product Highlights

This motor circuit protector is suitable for various applications, providing high short-circuit current ratings without the need for fuses, which helps save space and reduce spare parts requirements.

Product Information

Standard Information

• Brand: EATON
• Manufacturer: EATON

Technical Specifications

• Connection Type: Line/Load
• Amperage Rating: 100 A
• Series: C Series
• Voltage Rating: 600 VAC, 250 VDC
• Trip Range: 300 to 1000
• Trip Type: Magnetic
• Enclosure Type: NEMA 3
• Dimensions: 3.38 in L x 4.13 in W x 6 in H
• Number Of Poles: 3
• UPC: 782114209653
• GTIN: 00782114209653
• Minimum Order Qty: 1
• Standard & Approvals: ARRA, BuyAmerican Act, RoHS Compliant, CSA Certified, UL Listed
