Eaton HMCP070M2C Motor Circuit Protector 600 VAC 250 VDC 70 A 3 Poles

Product Description

The Eaton HMCP070M2C is a motor circuit protector that operates at 600 VAC and 250 VDC. It is a three-pole device rated for seventy amps, designed to provide reliable protection in commercial and institutional buildings. The molded case circuit breaker is suitable for a variety of applications, ensuring efficient operation and enhanced safety.

• 70 A current rating
• Three-pole design
• NEMA 2 starter compatible

Product Highlights

This circuit breaker is ideal for commercial applications requiring robust motor protection. The Eaton brand is known for high reliability and performance.

Product Information

Standard Information

• Manufacturer: Eaton
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: HMCP070M2C
• Frame Type: Frame J-K
• Dimensions: 7.7 inches x 4.9 inches x 4.9 inches
• Weight: 4.5 lb
• Amperage: 70 Amp
• Voltage Rating: 600 VAC, 250 VDC
• Applications: Commercial / Institutional Buildings
• Standards: CSA Certified, UL Listed
