Eaton HMCP003A0CA02 Motor Circuit Protector 3 A

Product Description

The Eaton HMCP003A0CA02 motor circuit protector is a three-pole motor circuit protector with a 3 A amperage rating. It features a 1A-1B left pigtail rear auxiliary switch, a 9-30 A magnetic trip range, and non-aluminum terminals. It is designed to comply with UL 489 and CSA Standard C22.2 No. 5.1.

• 3 A amperage rating
• 9-30 A magnetic trip range
• Complies with UL 489 and CSA Standard C22.2 No. 5.1

Product Highlights

The Eaton HMCP003A0CA02 is a reliable motor circuit protector with a 3A amperage rating.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: HMCP003A0CA02

Technical Specifications

• Product Name: Eaton molded case circuit breaker accessory motor circuit protector
• Catalog Number: HMCP003A0CA02
• UPC: 786679247860
• Product Length/Depth: 7.5 in
• Product Height: 4.8 in
• Product Width: 4.9 in
• Compliances: Contact Manufacturer
• Certifications: UL Listed CSA Certified
• Global Catalog: HMCP003A0CA02
• Product Type: Molded case circuit breaker accessory
• Amperage Rating: 3 A
• Auxiliary switch: 1A-1B Left pigtail rear
• Magnetic trip range: 9-30 A
• Series: Series C
• Terminal material: Non-aluminum
• Number of poles: Three-pole
• Type: Motor circuit protector
• Manufacturer: Eaton
• Component: Motor Circuit Protector
• UNSPSC Code: 39120000
• Brand: Eaton - Cutler Hammer
• Manufacturer Part Number: HMCP003A0CA02
• Connection Type: Line/Load Lug
• Enclosure Type: NEMA 0
• Frame: F
• Frequency Rating: 50/60 Hz
• Mounting Type: Panel
• Wire Size: 18 AWG
• Voltage Rating: 600 VAC/250 VDC
• Trip Type: Magnetic
• Trip Range: 9 to 30 A
