Eaton HMCP003A0 Motor Circuit Protector 3 A

Product Description

The EATON HMCP003A0 is a molded case circuit breaker accessory motor circuit protector. This three-pole motor circuit protector has a 3A amperage rating and a magnetic trip range of 9-30 A. It is part of the Series C and designed for frame J-K.

• 3 Amp
• Three-pole
• Feed-Thru

Product Highlights

The EATON HMCP003A0 motor circuit protector provides instantaneous protection and is suitable for motor FLA applications between 0.69-2.5A.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: HMCP003A0
• Country of Origin: United States

Technical Specifications

• Product Name: Eaton molded case circuit breaker accessory motor circuit protector
• Catalog Number: HMCP003A0
• UPC: 786679150702
• Product Length/Depth: 7.6 in
• Product Height: 4.9 in
• Product Width: 5.1 in
• Compliances: Contact Manufacturer
• Certifications: UL Listed CSA Certified
• Global Catalog: HMCP003A0
• Product Type: Molded case circuit breaker accessory
• Amperage Rating: 3 A
• Frame size: Frame J-K
• Magnetic trip range: 9-30 A
• Series: Series C
• Accessories: No accessory
• Number of poles: Three-pole
• Type: Motor circuit protector
• Brand: Eaton Cutler-Hammer
• Country of Origin: United States
• Manufacturer: Eaton Cutler-Hammer
• Pole: 3
• Amp: 3
• Phase: 3
• Category: Molded Case
• Connection: Feed Thru
• Functions: I - Instantaneous
• Protection: Thermal Magnetic
• AIC Ratings: 65kA@480V
• Voltage Maximum: 600VAC 250VDC
• Continuous Amps: 3A
• Trip Setting Amps: 9 to 30A
• Motor FLA: 0.69 - 2.5
• Terminals: Aluminum Lugs, CU/AL Wire
• Manufacturer Series: Series C
