Eaton HKP-R Bus Fuseholder 250 VAC (10 Pack)

Product Description

Eaton HKP-R is a bus fuseholder rated 250 VAC and 30 A. It is a panel-mount, vibration-resistant thermoset holder for 1/4 in diameter by 1-1/4 in length fuses, with a temperature rating of 150 deg C and overall dimensions of 0.79 in diameter x 2.33 in length. The unit includes standard plastic and optional metal nuts, a 9435-1/2 cap and a 9732 neoprene washer, and features a bayonet-type knob for panels up to 5/16 in thickness.

• Rated 250 VAC, 30 A; vibration-resistant design; temperature rating 150 deg C
• Panel-mount thermoset construction for 1/4 in x 1-1/4 in fuses; dimensions 0.79 in dia x 2.33 in L
• Includes standard plastic nut, optional metal nut, 9435-1/2 cap and 9732 neoprene washer; bayonet-type knob

Product Highlights

Panel-mount, vibration-resistant fuseholder for 1/4 in x 1-1/4 in fuses; thermoset construction; 250 VAC, 30 A rating.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: HKP-R

Technical Specifications

• Brand: Eaton
• Manufacturer Part Number: HKP-R
• Series: HKP
• Type: Standard vibration resistant
• Mounting Type: Panel
• Voltage Rating: 250 VAC
• Amperage Rating: 30 A
• Fuse Size: 1/4 in diameter x 1-1/4 in length
• Material: Thermoset
• Temperature Rating: 150 deg C
• Dimensions: 0.79 in diameter x 2.33 in length
• Includes: Standard plastic nut; optional metal nut; 9435-1/2 cap; 9732 neoprene washer
• Panel Thickness Compatibility: Up to 5/16 in
• Knob Type: Bayonet type knob
• Suitable For Use With: 1/4 in dia x 1-1/4 in fuse
• Standards/Approvals: RoHS Compliant; UL File No. E14853 Guide IZLT2; CSA File No. 47235 Class 6225-01; CE Certified
• Notes: Military version designated FHN26G1
