Eaton HFD3060 F Frame Molded Case Circuit Breaker 60A 600VAC/250VDC

Product Description

Eaton HFD3060 is a three-pole, fixed thermal and magnetic trip molded case circuit breaker. Rated at sixty amperes, it operates at six hundred volts AC or two hundred fifty volts DC. Ideal for use in panelboards, switchboards, motor control centers, and busway applications. This circuit breaker offers reliable protection and various application options.

• Three-pole configuration for versatile applications
• Fixed thermal and magnetic trip for dependable performance
• Rated for 65 kAIC interrupting capacity at six hundred volts AC

Product Highlights

This breaker allows for diverse connections including load side configurations. Suitable for high-performance electrical assemblies.

Product Information

Standard Information

• Brand: Eaton
• MPN: HFD3060

Technical Specifications

• Current Rating: 60 A
• Voltage Rating: 600VAC, 250VDC
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kAIC
• Dimensions: 3.38 in (L) x 4.13 in (W) x 6 in (H)
• Weight: 4.4 lb
• Frame Type: F
