Eaton HFD3030 Circuit Breaker 600 VAC/250 VDC 30 A

Product Description

The Eaton HFD3030 is a molded case circuit breaker designed for use in panelboards, switchboards, and motor control centers. This F-frame circuit breaker has a fixed thermal and magnetic trip type with three poles and a current rating of thirty amperes. It operates efficiently at both 600 volts alternating current and 250 volts direct current, making it suitable for various applications.

• Current rating of 30 A
• Utilizes fixed thermal and magnetic trip technology
• Rated for 600 Vac or 250 Vdc

Product Highlights

The Eaton HFD3030 is ideal for providing reliable branch circuit protection and has been trusted in the field for over 20 years.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: HFD3030
• Frame: F
• Number of Poles: 3
• Amperage Rating: 30 A
• Voltage Rating: 600 Vac, 250 Vdc
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Country of Origin: Dominican Republic
• Temperature Rating: 40 degrees Celsius
• Application: Panelboard, Switchboard, Motor Control Center, and Busway Applications
