Eaton HFD3025L CH Series C NEMA F-Frame Molded Case Circuit Breaker 25 A

Product Description

The EATON HFD3025L molded case circuit breaker, Type HFD, C Series, is rated at 600 VAC/250 VDC and 25 A. It operates at 50/60 Hz with interrupt capabilities of 65 kAIC at 480 VAC and 100 kAIC at 240 VAC. This 3-pole breaker features a fixed thermal/fixed magnetic trip and is suitable for panelboards, switchboards, motor control centers, busways, and electrical assemblies.

• Patented contact design features high speed "blow-open" action, resulting in superior performance
• Suitable for reverse feed applications
• 100 kA at 240 VAC, 65 kA at 480 VAC interrupt rating

Product Highlights

EATON HFD3025L circuit breaker with fixed thermal/fixed magnetic trip, ideal for various electrical applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: HFD3025L
• Country of Origin: China

Technical Specifications

• Actuator Type: Handle
• Amperage Rating: 25 A
• Application: Panelboard, Switchboard, Motor Control Center, Busway, Electrical Assemblies and OEMs Applications
• Connection Type: Line/Load
• Frame: F
• Frequency Rating: 50/60 Hz
• Manufacturer Part Number: HFD3025L
• Number of Poles: 3
• Series: C Series
• Standards/Approvals: AS 2184|BS 4752|CSA C22.2/5|Federal Specification WC-375B|HACR Rated|IEC 60947-2|SABS 156|SEV 157-1|UL 489|VDE 0660
• Temperature Rating: 40 deg C
• Trip Type: Fixed Thermal/Fixed Magnetic
• Type: Type HFD
• Voltage Rating: 600 VAC/250 VDC
• Brand: Eaton
• Model: HFD3025L
• Country of Origin: China
