Eaton HFD3020 Circuit Breaker 20A 3 Pole

Product Description

The Eaton HFD3020 is a molded case circuit breaker designed for reliable circuit protection in various applications. This circuit breaker operates at 20 Amps and is suitable for 600 VAC systems and 250 VDC systems. The HFD series is known for its efficient fixed thermal and fixed magnetic trip features.

• Type: Molded Case Circuit Breaker
• Amperage: 20 Amp
• Number of Poles: 3

Product Highlights

The Eaton HFD3020 circuit breaker is ideal for use in panelboards, switchboards, motor control centers, and busway applications. It provides essential overcurrent protection and meets UL standards for safety and reliability.

Product Information

Standard Information

• Manufacturer: Eaton
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: HFD3020
• Current Rating: 20 Amp
• Voltage Rating: 600 VAC, 250 VDC
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kAIC at 480 VAC, 100 kAIC at 240 VAC
• Frame Type: F
• Trip Type: Fixed Thermal/Fixed Magnetic
• Dimensions: 4.13 in W x 3.38 in L x 6 in H
